our advantages!
Top Manufacturer Of Honey Packing Machine Export More Than 40 Countries
30 Over Years Experience In Honey Packing Machine
Professional Honey Packing Machine Manufacturer, Easy Operation& Factory Price Inquire!
Honey Packing Machine Made In China CE/ISO/TUV Certifications
1. Multi lanes honey machines can produce multi lanes bags at the same time.
2. Machine main function: automatic split film at the right position, liquid measuring and filling, multi lanes bag form fill seal, cutting, sensor tracking, counting capacity.
3. Other functions: Emergency stop, set capacity to auto stop machine, count capacity and Zero the count, ready bag output, manual test machine each step, etc.
4. Stainless steel contact part and the machine outer shell, high feature for liquid running environment.
5. High-precision photocell sensor for auto-tracking the eye mark printing on the film roll, so cut each bag at a precise position.
6. PLC controller, high function and control the whole machine’s work steps.
This packaging machine is suitable for all kinds of paste, viscous liquid packaging, such as ketchup, jam, chili sauce, honey, pizza sauce, peanut butter, tartar sauce, chocolate sauce, chili sauce, cream, liquid butter, juice, shower gel, shampoo, etc.
Model | UB-4L | UB-6L | UB-8L | UB-12L |
Film width&Thickness | Max.480mm, 0.07-0.10mm | Max.680mm, 0.07-0.10mm | Max.800mm, 0.07-0.10mm | Max.900mm, 0.07-0.10mm |
Packing speed | 30-50bag/min/lane | |||
Air consumption | 0.65mpa | |||
Cutting type | Straight cutting, Zig zag cutting, Round cutting, Special cutting | |||
Powder | 2.0KW | 2.2KW | 3.0KW | 4.0KW |
Machine Weight | 400KG | 480KG | 550KG | 690KG |
Dimensions (mm) | 1100(L)*1080(W)*2100(H) | 1100(L)*1180(W)*2100(H) | 1100(L)*1200(W)*2100(H) | 1100(L)*1280(W)*2180(H) |
Bag type
